NetAXS™ NX4L1 Installation Guide
Installation
Use the following DIP switch configurations to set the panel address.
Note: Address 0 is not a valid setting.
Table 5 DIP Switch Settings
S1 S2 S3 S4 S5 S6 Selection
on off off off off Address 1 (default)
off on off off off
Address 2
on on off off off
Address 3
off off on off off
Address 4
on off on off off
Address 5
off on on off off
Address 6
on on on off off
Address 7
off off off on off
Address 8
on off off on off
Address 9
off on off on off
Address 10
on on off on off
Address 11
off off on on off
Address 12
on off on on off
Address 13
offonononoff
Address 14
on on on on off
Address 15
off off off off on
Address 16
on off off off on
Address 17
off on off off on
Address 18
on on off off on
Address 19
off off on off on
Address 20
on off on off on
Address 21
off on on off on
Address 22
on on on off on
Address 23
off off off on on
Address 24
on off off on on
Address 25
off on off on on
Address 26
on on off on on
Address 27
off off on on on
Address 28
on off on on on
Address 29
offonononon
Address 30
on on on on on
Address 31
off NetAXS Multidrop
on NetAXS Gateway
