NetAXS™ Standalone Operation
NetAXS Panel Defaults
NetAXS™ NX4L1 Access Control Unit Installation Guide, Document 7-901099V3 75
4.0 NetAXS Panel Defaults
4.1 Reader Ports
The panel accepts a Wiegand serial data packet from the card reader. If the card is in
the database, the associated relay is activated. If the card is not in the database, the
relay state is unchanged.
The following are the default reader port to relay associations:
4.2 Reader LED Outputs
The Reader LED output defaults to toggle the card reader LED from Red to Green for
two seconds when a valid card is presented. No LED color change (other then a
possible momentary change depending on reader used) occurs if the card is not in the
database.
The following are the default reader LED port to output associations:
Reader Number Controls...
1 Relay 1 (Output 1)
2 Relay 2 (Output 2)
3 Relay 3 (Output 3)
4 Relay 4 (Output 4)
Reader LED Controls...
Reader 1 Output 11
Reader 2 Output 12
Reader 3 Output 13
Reader 4 Output 14
