End of Line Termination
NetAXS™ NX4L1 Access Control Unit Installation Guide, Document 7-901099V3 83
5.0 End of Line Termination
By default, the controllers are not terminated. If the controller is the last one on the
485 bus then it should be terminated. For more information, see the controller’s
installation guide.
• NetAXS-123: Place SW1 DIP switches 8 and 9 to the ON position to terminate.
• NetAXIS: Place jumpers across J36 and J37 to terminate.
