NetAXS™ NX4L1 Installation Guide
Installation
Figure 4: NetAXS Panel Cabinet, Top View
Figure 5: NetAXS Panel Cabinet, Bottom View
0 1 31/32" (50 mm) 4 1/8" (105 mm)
1 5/8" (41 mm)
31/32" (25 mm)
0
13 19/32" (345 mm) 15 3/4" (400 mm)
Back
0
0
31/32" (25 mm)
1 5/8" (41 mm)
1 31/32" (50 mm)
4 1/8" (105 mm)
5 23/32" (145 mm) 8 27/32" (225 mm)
15 3/4"" (400mm)
13 19/32" (345 mm)
12" (305 mm)
Back
