Honeywell Pneumatic Controls User Manual

Valves
100 customer.honeywell.com 70-6925
Valve Type: Unitary
Body Pressure: 250 psi (1724 kPa)
Air Connections: 1/8 in. NPT
Controlled Medium: Water
Type of End Connection: 45 deg. SAE flare
Operating Humidity Range (% RH): 5 to 95% RH
Temperature Range: 35 F to 250 F (2 C to 121 C)
Maximum Actuator Temperature: 160 F (71 C)
Maximum Diaphragm Pressure: 25 psi (172 kPa)
Replacement Parts:
313824A Rebuild kit, include Stem and Disc holder, button with screw,
packing and instruction, VP522A1005
314459A Rebuild kit, include Stem and Disc holder, button with screw,
packing and instruction, VP522A1039
314459B Rebuild kit, includes stem and disc holder, Button with screw,
packing and instructions, VP522A1047
315407A Rebuild kit, include Stem and Disc holder, button with screw,
packing and instruction for the VP522B1003
312760 MP953A,C,E (5 in. diameter) regular temperature Neoprene
diaphragm - new style
312817S Actuator for VP522A1039, VP522A1047, VP522A1237
312817W Actuator for VP522B1003
312817Y Actuator assembly for VP522B1011 andVP522B1029
Product Number
End Connection Size
Body
Pattern
Valve
Action
Capacity Close-off
Ratings at
Branchline
Pressure
Spring Range
(inch) (mm) (Cv) (Kv) (psi) (kPa)
VP522A1005 O.D.: 1/2 in.;
Nominal:
3/8 in.
O.D.: 12.7 mm;
Nominal:
9.5 mm
Three-way
Mixing
Proportional/
Sequencing
Port A: 1.5 Cv,
Port B: 1.5 Cv
Port A: 1.3 Kv,
Port B: 1.3 Kv
50 psid at
13 psi
3 psi to
11.5 psi
21 kPa to
79 kPa
VP522A1039 O.D.: 5/8 in.;
Nominal:
1/2 in.
O.D.: 15.9 mm;
Nominal:
12.7 mm
Three-way
Mixing
Proportional/
Sequencing
Port A: 2.5 Cv,
Port B: 1.6 Cv
Port A: 2.2 Kv,
Port B: 1.4 Kv
50 psid at
13 psi
2 psi to 13
psi
14 kPa to
90 kPa
VP522A1047 O.D.: 7/8 in.;
Nominal:
3/4 in.
O.D.: 22.2 mm;
Nominal:
19.1 mm
Three-way
Mixing
Proportional/
Sequencing
Port A: 4 Cv,
Port B: 2.5 Cv
Port A: 3.5 Kv,
Port B: 2.2 Kv
45 psid at
13 psi
2 psi to 13
psi
14 kPa to
90 kPa
VP522B1003 O.D.: 1/2 in.;
Nominal:
3/8 in.
O.D.: 12.7 mm;
Nominal:
9.5 mm
Three-way
Diverting,
Sequencing
Diverting/
Sequencing
Port A: 1.5 Cv,
Port B: 1.5 Cv
Port A: 1.3 Kv,
Port B: 1.3 Kv
15 psid at
13 psi
Adjustable Adjustable
VP522B1011 O.D.: 5/8 in.;
Nominal:
1/2 in.
O.D.: 15.9 mm;
Nominal:
12.7 mm
Three-way
Diverting,
Sequencing
Diverting/
Sequencing
Port A: 2.5 Cv,
Port B: 2.5 Cv
Port A: 2.2 Kv,
Port B: 2.2 Kv
15 psid at
13 psi
Adjustable Adjustable
VP522B1029 O.D.: 7/8 in.;
Nominal:
3/4 in.
O.D.: 22.2 mm;
Nominal:
19.1 mm
Three-way
Diverting,
Sequencing
Diverting/
Sequencing
Port A: 4 Cv,
Port B: 3.5 Cv
Port A: 3.5 Kv,
Port B: 3.0 Kv
15 psid at
13 psi
Adjustable Adjustable
