Honeywell Pneumatic Controls User Manual

Valves
110 customer.honeywell.com 70-6925
Pneumatic Valve Replacement Parts
Product Number Description Used With
14000639-001 Washer VP526
14001046-004 Fastener VP526A; VP527A; VP525A,C;
VP531A,C
14001101-001 Valve Position Indicator VP525
14002560-002 Stem and Disk Assembly VP527A1018; VP527A1059
14002560-004 Stem and Disk Assembly VP527A1034; VP527A1075
14002560-006 Stem and Disk Holder Assembly. For 0.63 Cv VP525 Valve VP525
14002560-007 Repair stem assembly for 1/2 inch, 2.0 Cv VP525C or to Upgrade, 2.0 Cv VP525A VP525A; VP525C
14002560-008 Repair stem assembly for 1/2 and 3/4 inch, 3.0 Cv VP525C or to Upgrade 1/2 and 3/4 inch, 3.0 Cv
VP525A
VP525A; VP525C
14002560-009 Repair stem assembly for 3/4 inch, 5.0 Cv VP525C or to Upgrade, 5.0 Cv VP525A VP525A; VP525C
14002560-010 Repair stem assembly, 1.6 Cv VP531C or to Upgrade, 1.6 Cv VP531A VP531A; VP531C
14002560-011 Repair stem assembly for 2.6 Cv VP531C or to Upgrade 2.6 Cv VP531A VP531A; VP531C
14002560-012 Repair stem assembly for 3.3 Cv VP531C or to Upgrade 3.3 Cv VP531A VP531A; VP531C
14002560-013 Repair stem assembly for 1/2 inch, 0.63 Cv VP525C or to Upgrade, 0.63 Cv VP525A VP525A; VP525C
14002863-001 Valve rebuild kit for 3/4 to 1 1/4 in valves with Cv of 6.3 or 10 VP512
14003297-001 Valve repack kit for VP526A, VP527A, or VP531A valves with 3/16 inch stem VP526A; VP527A; VP531A
14003297-002 Teflon packing kit for VP531C or VP531A upgrade valves VP531A; VP531C
14003299-001 Repair Top & Insert for 5/8 in. OD, 1.6 Cv VP525A solder body VP525A
14003300-001 Repair Top & Insert for 7/8 in. OD, 2.5 Cv VP525A solder body VP525A
14003308-001 Valve Bonnet VP531A; VP531C
14003314-001 1 1/4 inch hex stainless steel Bonnet nut, Finish zinc plate with Dichromate treatment. VP531A; VP531C
14003352-001 Seal washer, 1 1/64 outside diameter X 7/8 inside diameter VP531A; VP531C
14003382-001 Brass Hex Bonnet 1-1/2 in. diameter VP526A; VP525C
14003475-001 Valve Rebuild Kit for 1/2 in. valve with 0.4 or 0.63 Cv VP527A
14003476-001 Valve Rebuild Kit for 1/2 in. valve with 1 or 1.6 Cv VP527A
14004845-001 Green Packing Spring VP525A; VP525C; VP531C
14004897-001 Repair Top & Insert for 1/2 inch NPT, 0.63 Cv VP525C or to upgrade 1/2 NPT, 0.63 Cv VP525A VP525A; VP525C
14004897-002 Repair Top & Insert for 1/2 inch NPT, 2.0 Cv VP525C or to upgrade 1/2 NPT, 2.0 Cv VP525A VP525A; VP525C
14004897-003 Repair Top & Insert for 3/4 inch NPT, 3.0 Cv VP525C or to upgrade 3/4 NPT, 3.0 Cv VP525A VP525A; VP525C
14004897-004 Repair Top & Insert for 3/4 inch NPT, 5.0 Cv VP525C or to upgrade 3/4 NPT, 5.0 Cv VP525A VP525A; VP525C
14004898-001 Repair Top & Insert for NPT and Solder body, 1.6 Cv VP531C or to upgrade NPT and solder body, 1.6
Cv VP531A
VP531A; VP531C
14004898-002 Repair Top & Insert for NPT and Solder body, 2.3 and 2.6 Cv VP531C or to upgrade NPT and solder
body, 2.3 and 2.6 Cv VP531A
VP531A; VP531C
14004898-003 Repair Top & Insert for NPT and Solder body, 3.3 Cv VP531C or to upgrade NPT and solder body, 3.3
Cv VP531A
VP531A; VP531C
310135 Packing Spring, 1 Required VP513A,B; VP522A,B
310137 Spacer for VP513 or VP517 Valves VP513A,B; VP522A,B
310143 Black Packing, 3 required VP513A,B; VP522A,B
310208 White Packing VP525C; VP531C
312826 O-Ring —
313051 1/2 inch valve Union Nut for VP525 VP501; VP500; VP525A,C
313052 3/4 inch valve Union Nut for VP525 VP501; VP500; VP525A,C
313102 Disc for VP513A Valves VP513A
313744A Actuator Replacement Assembly for the VP519 Valve VP519C
314482 Stainless Steel Stem for 1/4 inch VP517A Valves VP522A; VP517A
314526 Orange Spring with Blue stripe, 3 to 10 psi, 1/2 in. stroke VP517A; VP513A; 312817T
