Honeywell Pneumatic Controls User Manual

Velocity Sensors/Controllers
32 customer.honeywell.com 70-6925
CP980C,D,E, and F Cross-Reference Table
.
a
Valid with green (1500 ft/min), red (2500 ft/min), white (3500 ft/min) or blue (4250 ft/min) orifices only.
Current Order
Number
(Less Orifice) Orifice Order No.
Velocity Range
ft/min (m/s) Orifice Set
Replaces Honeywell
Original Set Less
Orifice
Interim Matched
Set
(Less Orifice)
Matched Set
(Includes Orifice)
CP980C1065 None 500 (2.5) None — — —
14003642-002 750 (3.8) Green CP980C1016
14003642-003 1500 (7.6) White CP980C1024
14003642-004 2000 (10.2) Blue CP980C1032
14003749-001 2500 (12.7) Black CP980C1040
14003749-002 3500 (17.8) Gray CP980C1057
CP980D1063 None 500 (2.5) None CP980A1002/ CP980B1000 —
14003642-002 750 (3.8) Green RP980A1006 or CP980D1014
14003642-003 1500 (7.6) White or CP980B1018 CP980D1022
14003642-004 2000 (10.2) Blue CP980A1002/ CP980D1030
14003749-001 2500 (12.7) Black RP980B1004 CP980D1048
14003749-002 3500 (17.8) Gray CP980B1034 CP980D1055
RP980A1006 CP980A1010/
or or
RP980A1010/ CP980B1042
RP980B1004
CP980E1060 None 500 (2.5) None — — —
14003642-002 750 (3.8) Green CP980E1011
14003642-003 1500 (7.6) White CP980E1029
14003642-004 2000 (10.2) Blue CP980E1037
14003749-001 2500 (12.7) Black CP980E1045
14003749-002 3500 (17.8) Gray CP980E1052
CP980F1068 None 500 (2.5) None CP980A1002/ CP980B1026 —
14003642-002 750 (3.8) Green RP980C1002 CP980F1019
14003642-003 1500 (7.6) White CP980A1010/
CP980B1059
a
CP980F1027
14003642-004 2000 (10.2) Blue
RP980C1002
a
CP980F1035
14003749-001 2500 (12.7) Black CP980F1043
14003749-002 3500 (17.8) Gray CP980F1050
