Honeywell Pneumatic Controls User Manual

Thermostats
10 customer.honeywell.com 70-6925
**A Tradeline Kit includes a TP970 Series thermostat with either a Satin Chrome or Beige Universal Cover, Windows (horizontal (F), vertical (F)
and blank) for new installations or to convert newer, small size Honeywell or competitor thermostat, not requiring a wall plate adapter.
A Convertastat Kit™ includes a TP970 Series thermostat with either a Satin Chrome or Beige Universal Cover, Windows (horizontal (F), vertical
(F) and blank) and a small Universal Wall Plate Adapter to convert newer, small size Honeywell or competitor thermostats.
A Modernization Kit includes a TP970 Series thermostat with Satin Chrome Universal Cover, Windows (horizontal (F), vertical (F) and blank)
and a large Universal Wall Plate Adapter to convert older thermostats.
Product
Number Action
Setpoint
Temperature
Range Throttling Range
Includes Comments**(F) (C) (F) (C)
TP970A2004 Direct Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Order Cover Separately —
TP970A2012 Direct Acting 40 F to
70 F
— 2 F to 10 F
(factory set 4 F)
— Order Cover Separately —
TP970A2020 Direct Acting — 15 C to
30 C
— 1 C to 5 C
(factory set 2 C)
Order Cover Separately —
TP970A2038 Direct Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat, large wall plate
and satin chrome cover.
Modernization kit used to
convert older Honeywell
Thermostats.
TP970A2053 Direct Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat, large wall plate
and satin chrome cover.
Modernization kit used to
convert older Honeywell
Thermostats and competitive
thermostats.
TP970A2145 Direct Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat, small wall plate
and satin chrome cover.
Convertastat Kit
TP970A2234 Direct Acting — 15 C to
30 C
— 1 C to 5 C
(factory set 2 C)
Thermostat, small wall plate
and satin chrome cover.
Convertastat Kit
TP970A2242 Direct Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat, small wall plate
and beige cover.
Convertastat Kit
TP970A2259 Direct Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat and satin
chrome cover.
Tradeline Kit
TP970A2283 Direct Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat and beige cover. Tradeline Kit
TP970B2002 Reverse Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Order Cover Separately —
TP970B2010 Reverse Acting — 15 C to
30 C
— 1 C to 5 C
(factory set 2 C)
Order Cover Separately —
TP970B2077 Reverse Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat, small wall plate
and satin chrome cover.
Convertastat Kit
TP970B2150 Reverse Acting — 15 C to
30 C
— 1 C to 5 C
(factory set 2 C)
Thermostat, small wall plate
and satin chrome cover.
Convertastat Kit
TP970B2166 Reverse Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat, small wall plate
and beige cover.
Convertastat Kit
TP970B2182 Reverse Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat and satin
chrome cover.
Tradeline Kit
TP970B2216 Reverse Acting 60 F to
90 F
— 2 F to 10 F
(factory set 4 F)
— Thermostat and beige cover. Tradeline Kit
TP970C2000 Direct Acting 60 F to
90 F
— 5 F to 25 F — Order Cover Separately Wide Throttling Range 5-25 F
