Honeywell ST 800 Series User Manual

Revision 5.0 ST 800 Series HART/DE Option User’s Manual Page 45
Online/Device
Setup/Display
Setup
(Continued …)
(for Basic Display
Only)
Read Screen Info
Displays configured information for each of the eight
display screens. Select a screen number to view details of
the configurations selected in the “Screen Configuration”
menu.
Screen
Configuration
The display screen may be customized with the following
settings:
PV Selection: select the displayed process variable as:
Differential Pressure
Loop Output
Percent Output
Pressure Units: select desired standard pressure unit.
Number of Decimals: select the number of decimal
places for the PV display from none to 3.
Custom Tag: enter a custom tag name for the screen
title up to 14 alphanumeric characters.
Common Setup
The following screen options are available:
Rotation Time: Set the length of time the PV display is
visible before rotating to another screen (such as a
diagnostic display). Select from 3 to 30 seconds.
Contrast Level: Select a display contrast level from
1(low) to 9 (high) or choose the “default” (5).
Online/Device
Setup/Upgrade
Options
PILD
Functionality
Provides information to user to if PILD functionality which is
an optional feature is Available or Not-Available.
Dev Id
This is the Device identification which user needs to provide
to get valid License Key for upgrading new features like
PILD.
Enter License
Key
License Key used to enable specific feature or function
Online/Device
Setup/Review
Displays the current values for all of the pertinent operating
parameters listed in this table, plus revision information.
Parameters are not configurable in this menu.
