Xenon/Granit User Guide 301
*Imaging Style - Photo SNPSTY1 242
Imaging Style - Manual SNPSTY2 242
Beeper On SNPBEP1 242
*Beeper Off SNPBEP0 242
*Wait for Trigger Off SNPTRG0 243
Wait for Trigger On SNPTRG1 243
*LED State - Off SNPLED0 243
LED State - On SNPLED1 243
Exposure (1-7874 microseconds) SNPEXP 243
*Gain - None SNPGAN1 244
Gain - Medium SNPGAN2 244
Gain - Heavy SNPGAN4 244
Gain - Maximum SNPGAN8 244
Target White Value (0-255) *125 SNPWHT### 244
Delta for Acceptance (0-255) *25 SNPDEL### 244
Update Tries (0-10) *6 SNPTRY## 245
Target Set Point Percentage (1-
99) *50
SNPPCT## 245
Image Ship *Infinity Filter - Off IMGINF0 246
Infinity Filter - On IMGINF1 246
*Compensation Off IMGCOR0 246
Compensation On IMGCOR1 246
*Pixel Depth - 8 bits/pixel
(grayscale)
IMGBPP8 246
Pixel Depth - 1 bit/pixel (B&W) IMGBPP1 246
*Don’t Sharpen Edges IMGEDG0 247
Sharpen Edges (0-23) IMGEDG## 247
*File Format - JPEG IMGFMT6 248
File Format - KIM IMGFMT0 248
File Format - TIFF binary IMGFMT1 248
File Format - TIFF binary group 4,
compressed
IMGFMT2 248
File Format - TIFF grayscale IMGFMT3 248
File Format - Uncompressed
binary
IMGFMT4 248
File Format - Uncompressed
grayscale
IMGFMT5 248
File Format - BMP IMGFMT8 248
*Histogram Stretch Off IMGHIS0 248
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page
