Honeywell Xenon Series User Manual

302 Xenon/Granit User Guide
Histogram Stretch On IMGHIS1 248
*Noise Reduction Off IMGFSP0 249
Noise Reduction On IMGFSP1 249
Invert Image around X axis IMGNVX1 249
Invert Image around Y axis IMGNVY1 249
Rotate Image none IMGROT0 250
Rotate Image 90° right IMGROT1 250
Rotate Image 180° right IMGROT2 250
Rotate Image 90° left IMGROT3 250
JPEG Image Quality (0-100) *50 IMGJQF### 250
*Gamma Correction Off IMGGAM0 251
Gamma Correction On (0-1000) IMGGAM### 251
Image Crop - Left (0-843) *0 IMGWNL### 251
Image Crop - Right (0-843) *843 IMGWNR### 251
Image Crop - Top (0-639) *0 IMGWNT### 251
Image Crop - Bottom (0-639)
*639
IMGWNB### 252
Image Crop - Margin (1-238) *0 IMGMAR### 252
Protocol - None (raw) IMGXFR0 252
Protocol - None (default USB) IMGXFR2 252
Protocol - Hmodem Compressed IMGXFR3 252
Protocol - Hmodem IMGXFR4 252
Ship Every Pixel IMGSUB1 253
Ship Every 2nd Pixel IMGSUB2 253
Ship Every 3rd Pixel IMGSUB3 253
*Document Image Filter Off IMGUSH0 253
Document Image Filter On (0-
255)
IMGUSH### 253
*Don’t Ship Histogram IMGHST0 254
Ship Histogram IMGHST1 254
Image Size Compatibility Force VGA Resolution IMGVGA1 254
*Native Resolution IMGVGA0 255
Intelligent Signature Capture Optimize On DECBND1 255
*Optimize Off DECBND0 255
Utilities
Add Code I.D. Prefix to All Symbologies (Temporary) PRECA2,BK2995C80! 261
Show Decoder Revision REV_DR 261
Show Scan Driver Revision REV_SD 261
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page

Honeywell Xenon Series Specifications

General

IP Rating	IP42
Connectivity	USB, RS-232, Keyboard Wedge, IBM 46XX, Synapse, USB-CDC
Decode Capabilities	1D and 2D barcodes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Light Levels	Ambient light up to 100, 000 lux
Field of View	Horizontal: 41.4°; Vertical: 32.2°
Interface	USB, RS-232, Keyboard Wedge, IBM 46XX
Humidity	5% to 95% (non-condensing)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Drop Resistance	Withstands 50 drops at 1.8 m (6 ft) to concrete
Drop Specification	Withstands 50 drops at 1.8 m (6 ft) to concrete
