3-70 ES User’s Guide
Making Measurements
Measuring Group Delay
TIP An optimum calibration is critical for achieving best measurement
accuracy. Refer to Chapter 6, “Calibrating for Increased Measurement
Accuracy, for detailed information about all of the various aspects of
calibration.
NOTE Phase-derived delay cannot be used to measure frequency-translating
devices.
Enter the Measurement Parameters
1. Press the following keys on the analyzer:
( or )
2. Choose an aperture. When choosing an aperture, there is a trade-off
between minimum apertures (giving more resolution but noisier
responses) and maximum apertures (giving less resolution but
smoother responses). For this example, choose an aperture of 4% by
pressing:
PRESET
User Preset
Factory Preset
MEAS 1
S21 Fwd Trans
FORMAT
Delay
FREQ
Center
175
MHz
Span
200
MHz
AVG
Delay Aperture
Aperture (%)
4
Enter
