4-48 ES User’s Guide
Using Instrument Functions
Customizing the Display
1. To turn on/off the graticule, press
. This softkey toggles the display graticule on and
off.
2. To turn on/off the limit line or point, press
. This softkey toggles the
limit line or point on and off. Turning limit lines or points off does not
turn limit testing off.
NOTE You cannot turn off the delta amplitude or delta frequency limit
indicators.
Modifying Display Annotation
When you first turn on your analyzer, or use the
( or ) keys to return it to the default
condition, most of the display annotation is visible. You may want to
modify or turn on or off some of the annotation to customize the display
to your preferences. Figure 4-22, “The Display Annotation,” shows the
display screen and points out the different annotation areas. Some of
these areas can be modified, and all of them can be turned on or off.
DISPLAY
DISPLAY
PRESET
