HP 8712ET User Manual

ES User’s Guide 8-47
Hardkey/Softkey Reference
L
Softkey in the menu. Sets the RF power level of the
analyzer's source.
See Chapter 9, “Specifications,” for the minimum and maximum power
levels for your analyzer.
Softkey in the max point or min point menus. Sets the amplitude of a
limit point.
See “To Create a Single Point Limit” on page 4-32 for an example of
how to set a limit point.
Access Keys: ,
or
Softkey in the limit options menu. Disables the fail indicator from
being displayed on the analyzer's screen. Does not disable PASS or
FAIL text. Pass/fail text can be disabled with the
softkey.
See “Customizing the Display” on page 4-45 for more information.
Access Keys:
Softkey in the limit options menu. Allows for customizing the position
of the pass/fail indicator and text on the analyzer's display.
See “Customizing the Display” on page 4-45 for more information.
Access Keys:
Softkey in the limit options menu. Allows for customizing the position
of the pass/fail indicator and text on the analyzer's display.
See “Customizing the Display” on page 4-45 for more information.
Access Keys:
Softkey in the menu. Displays the limit-testing menu to
select, display, add, delete, and edit limit lines and other limit tests.
See “Using Limit Testing” on page 4-28 for more information.
Level
POWER
Limit
DISPLAY
Limit Menu
Add Limit
Add Max Point
Add Min Point
Limit Icon
ON off
Limit Text ON off
DISPLAY
Limit Menu
Limit Options
Limit Icon
X Position
DISPLAY
Limit Menu
Limit Options
Limit Icon
Y Position
DISPLAY
Limit Menu
Limit Options
Limit Menu
DISPLAY
