8-62 ES User’s Guide
Hardkey/Softkey Reference
N
Softkey in the IBASIC display menu. Displays the measurement data
on the full screen. (Does not show the IBASIC program on the display
at all.)
Softkey in the menu. Equivalent to selecting
and . Corrects for frequency response
errors only. The only type of measurement "calibration" (other than
detector zero) for power or conversion loss measurements.
NOTE This type of "calibration" is not interpolated:
changes in frequency or the number of points
invalidate it.
See “To Perform a Normalization Calibration” on page 6-14 for more
information.
Softkey in the menu. Toggle to ON if you want to select the
normalize “calibration” described above.
Softkey in the marker search menu. Automatically calculates −6 dB
(default) or other user-specified bandwidth, center frequency, and Q of
a notch filter.
See “Using Markers” on page 4-3 for more information.
Access Keys:
Softkey in the source . Allows selection of the number of
measurement points in a sweep: 3, 5, 11, 21, 51, 101, 201 (default),
401, 801, or 1601. As the number of points increases, frequency
resolution increases and sweep speed decreases.
See “To Reduce the Number of Measurement Points” on page 5-5 for
information on how the number of measurement points selected can
affect your measurements.
Softkey in the clock format menu. Formats the real-time internal clock
to display the number of the month (for example, 03 for March).
Access Keys:
None
Normalize
DISPLAY
Data->Mem
Data/Mem
Normalize
on OFF
CAL
Notch
MARKER
Marker Search
Number of
Points
MENU
Numeric
SYSTEM OPTIONS
System Config
Set Clock
Clock Format
