Hardkey/Softkey Reference
P
Softkey in the menu. Adds or subtracts a phase offset that is
constant with frequency (rather than linear).
Softkey in the more format menu. Displays a polar format. Each point
on the polar format corresponds to a particular value of both
magnitude and phase. Quantities are read vectorally: the magnitude at
any point is determined by its displacement from the center (which has
zero value), and the phase by the angle counterclockwise from the
positive x-axis. Magnitude is scaled in a linear fashion, with the value
of the outer circle usually set to a ratio value of 1. Since there is no
frequency axis, frequency information is read from the markers.
Softkey in the port extensions menu. Allows compensation for phase
shift due to an extended measurement reference plane on port 1.
See “Port Extensions” on page 5-18 for more information.
Access Keys:
Softkey in the port extensions menu. Allows compensation for phase
shift due to an extended measurement reference plane on port 2.
See “Port Extensions” on page 5-18 for more information.
Access Keys:
Softkey in the port extensions menu. Toggle to ON if you want to
compensate for phase shift due to an extended measurement reference
plane.
See “Port Extensions” on page 5-18 for more information.
Access Keys:
Softkey in the define printer menu. Sets printer to print hardcopy so
that paper is oriented with shorter edge at top and longer edges at
sides. Portrait is the default setting, and toggles with Landscape.
Access Keys:
Phase Offset
SCALE
Polar
Port 1
Extension
CAL
More Cal
Port Extensions
Port Ext’s on OFF
Port 2
Extension
CAL
More Cal
Port Extensions
Port Ext’s on OFF
Port Ext's
on OFF
CAL
More Cal
Port Extensions
Portrait
HARDCOPY
Define Printer
