Troubleshooting 78
CAUTION: The server is designed to be electrically grounded (earthed). To ensure proper
operation, plug the AC power cord into a properly grounded AC outlet only.
Insight Display errors
The enclosure installation is successful when all errors are corrected. The errors in the following sections are
specific to installation and initial configuration of the enclosure. To clear errors that occur after initial
powerup and configuration, see the HP BladeSystem Onboard Administrator User Guide for information.
The following types of errors can occur when installing and configuring the enclosure:
• Power errors (on page 78)
• Cooling errors (on page 78)
• Location errors (on page 79)
• Configuration errors (on page 79)
• Device failure errors (on page 79)
When the enclosure UID LED is off, the Insight Display is illuminated amber when any error condition exists.
The navigation bar displays the following selections when an error condition exists:
• Health summary icon—Displays the Health Summary screen.
• Fix THIS—Suggests corrective action to clear the current error.
• Next Alert—Displays the next alert, or if none exist, displays the Health Summary screen.
• Previous Alert—Displays the previous alert.
Power errors
Power errors can occur because of insufficient power to bring up an enclosure. Power errors can occur on
blades, storage blades, or interconnect modules.
To correct a power error:
1. Use the arrow buttons to navigate to Fix This, and press OK.
2. Review and complete the corrective action suggested by the Insight Display. In most cases, you must
either add power supplies to the enclosure or remove the indicated components.
Cooling errors
Cooling errors occur when too few fans are installed in the enclosure or when the existing fans are not
installed in an effective configuration. Cooling errors can occur on blades, storage blades, or interconnect
modules.
To correct a cooling error:
1. Use the arrow buttons to navigate to Fix This, and press OK.
2. Review and complete the corrective action suggested by the Insight Display. In most cases, you must
either add fans to the enclosure, correct the fan configuration, or remove the indicated components.
