HP BladeSystem c7000 Maintenance And Service Guide

Illustrated parts catalog 22
Item Description Spare part number
Customer self repair (on
page
5
)
g) Brocade 4Gb SAN Switch for HP
c-Class BladeSystem, 24 ports, with Power
Pack Software*
411122-001 Mandatory
1
h) Cisco Catalyst Blade Switch 3020 for
HP c-Class BladeSystem*
432904-001 Mandatory
1
i) HP 1/10Gb Virtual Connect Ethernet
Module for c-Class BladeSystem*
399725-001 Mandatory
1
j) HP 4Gb Virtual Connect Fibre Channel
Module for c-Class BladeSystem*
410152-001 Mandatory
1
k) HP 4X DDR IB Switch Module for HP
c-Class BladeSystem*
410408-001 Mandatory
1
l) HP BLc 1/10GB-F Virtual Connect Enet
Module*
447103-001 Mandatory
1
m) Cisco MDS 9124e 12-port Fabric
Switch*
444572-001 Mandatory
1
n) Cisco MDS9124e 24-port Fabric
Switch*
444573-001 Mandatory
1
o) 8-GB 12-port SAN switch* 489864-001 Mandatory
1
p) 8-GB 24-port SAN switch* 489865-001 Mandatory
1
q) 8-GB 16-port SAN switch with power
pack and licensed features*
489866-001 Mandatory
1
r) HP BLc Cisco 1/10GbE 3120X Switch* 451357-001 Mandatory
1
s) HP BLc Cisco 1GbE 3120G Switch* 451356-001 Mandatory
1
t) HP 6120G/BX, Blade Switch* 508090-001 Mandatory
1
u) Switch, 10Gb Ethernet, c-Class* 517994-001 Mandatory
1
v) Module BLc VC8Gb 20 Port FC* 572216-001 Mandatory
1
w) HP BLc VC Flex-10/10D Module* 639852-001 Mandatory
1
x) HP Virtual Connect FlexFabric
10Gb/24-port Module for c-Class
BladeSystem*
572213-001 Mandatory
1
y) HP 6125G Ethernet Blade Switch* 663656-001 Mandatory
1
z) HP 6125G/XG Ethernet Blade Switch* 663658-001 Mandatory
1
18
Interconnect module (Pass-Thru) — —
a) HP 1Gb Ethernet Pass-Thru Module for
c-Class BladeSystem
419329-001 Mandatory
1
b) HP 4 Gb Fibre Channel Pass-Thru
Module for c-Class BladeSystem*
416378-001 Mandatory
1
c) 10Gb Pass-Thru, BNT* 504624-001 Mandatory
1
19
Onboard Administrator — —
a) HP BladeSystem Onboard Administrator 414055-001 Mandatory
1
b) HP c7000 Onboard Administrator with
KVM*
503826-001 Mandatory
1
20
Onboard Administrator tray — —
a) Onboard Administrator tray 416000-001 Mandatory
1

HP BladeSystem c7000 Specifications

General

Form Factor	10U
Number of Bays	16
Redundant Power	Yes
Redundant Fans	Yes
Maximum Blade Servers	16 half-height or 8 full-height
Operating Temperature	10° to 35°C (50° to 95°F)
Power Supplies	Up to 6
Cooling Fans	10
Management	Onboard Administrator
Interconnect Modules	Up to 8
Networking Options	Ethernet, Fibre Channel, InfiniBand
Compatibility	HP ProLiant and Integrity server blades
Relative Humidity	10% to 90% (non-condensing)
