HP BladeSystem c7000 Maintenance And Service Guide

Illustrated parts catalog 23
Item Description Spare part number
Customer self repair (on
page
5
)
b) Onboard Administrator tray (RoHS)* 519346-001 Mandatory
1
21
Active Cool 200 fan 413996-001 Mandatory
1
22
Midplane assembly — —
a) Midplane assembly 414050-001 No
3
b) Midplane assembly (RoHS)* 519345-001 No
3
c) Midplane assembly, AMP* ** (includes
the rear cage)
689229-001 No
3
23
Insight Display connector board
—
a) Insight Display connector board 416001-001 No
3
b) Insight Display LCD connector board
(RoHS)*
519347-001 No
3
24
AC module — —
a) AC input module, single-phase* 413494-001 Mandatory
1
b) AC module, single-phase, Intelligent 666226-001 Mandatory
1
c) AC input module, single phase,
HVDC*†
754219-001 Mandatory
1
25
Three-phase AC input module, North
America and Japan
413495-001 Mandatory
1
26
Three-phase AC input module,
international*
413496-001 Mandatory
1
27
DC input module* 544661-001 Mandatory
1
28
HP c-Class Blade SUV cable* 416003-001 Mandatory
1
29
USB cable for the single-phase intelligent
power input module*
711595-001 Mandatory
1
*Not shown
** Platinum models only
† This component is available on the following enclosure models:
• 681840-b21
• 681842-b21
• 681844-b21
• 763850-b21
1
Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be
charged for the travel and labor costs of this service.
2
Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If,
however, you require that HP replace them for you, there may or may not be additional charges, depending on the type
of warranty service designated for your product.
3
No—Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires that
an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts Catalog.
1
Mandatory: Obligatoire—Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP de
remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés.
2
Optional: Facultatif—Pièces pour lesquelles la réparation par le client est facultative. Ces pièces sont également
conçues pour permettre au client d'effectuer lui-même la réparation. Toutefois, si vous demandez à HP de remplacer ces
pièces, l'intervention peut ou non vous être facturée, selon le type de garantie applicable à votre produit.

HP BladeSystem c7000 Specifications

General

Form Factor	10U
Number of Bays	16
Redundant Power	Yes
Redundant Fans	Yes
Maximum Blade Servers	16 half-height or 8 full-height
Operating Temperature	10° to 35°C (50° to 95°F)
Power Supplies	Up to 6
Cooling Fans	10
Management	Onboard Administrator
Interconnect Modules	Up to 8
Networking Options	Ethernet, Fibre Channel, InfiniBand
Compatibility	HP ProLiant and Integrity server blades
Relative Humidity	10% to 90% (non-condensing)
