Time Protocols
SNTP: Viewing, Selecting, and Configuring
Time Protocol Selection Parameter
–TIMEP
–SNTP
–None
Figure 9-1. The System Information Screen (Default Values)
2. Press [E] (for E
dit). The cursor moves to the System Name field.
3. Use [v] to move the cursor to the Time Sync Method field.
4. Use the Space bar to select SNTP, then press [v] once to display and move
to the SNTP
Mode field.
5. Do one of the following:
• Use the Space bar to select the Broadcast mode, then press
[v] to
move the cursor to the Poll Interval field, and go to step 6. (For
Broadcast mode details, refer to “SNTP Operating Modes” on
page 9-2.)
Figure 9-2. Time Configuration Fields for SNTP with Broadcast Mode
• Use the Space bar to select the Unicast mode, then do the
following:
9-6
