Monitoring and Analyzing Switch Operation
Traffic Mirroring
CLI: Configuring Local and Remote Mirroring
Command Page
Quick Reference
Local Mirroring Commands
Remote Mirroring Commands
B-38
B-39
Configuring a Session Destination on a Remote Exit Switch
mirror endpoint ip
< src-ip > < src-udp-port > < dst-ip > < port-# > B-41
Configuring a Local Destination on a Session Source Switch
mirror < 1 - 4 > [name < name-str >] port < port-# >
B-43
Configuring a Remote Destination on a Session Source Switch
mirror < 1 - 4 > [name < name-str >] remote ip
< src-ip > < src-udp-port > < dst-ip > B-44
Defining Traffic To Mirror on a Session Source Switch
interface < port/trunk/mesh > monitor
all < in | out | both > mirror
ip access-group < acl-name > in mirror
vlan < vid-# > monitor
all < in | out | both > mirror
ip access-group < acl-name > in mirror
B-48
B-52
B-50
B-54
Display Commands
show monitor [endpoint | 1 - 4 | name < name-str >]
B-56
Mirroring Examples B-62
Maximum Frame Size B-68
Operating Notes B-70
Using the CLI you can configure a mirroring session to an exit port on either
the same switch as the source interface (local mirroring) or on another switch
(remote mirroring). (The remote switch must be a ProCurve switch offering
the full mirroring capabilities described in this chapter.)
