Monitoring and Analyzing Switch Operation

Traffic Mirroring

Displaying the Remote Endpoint Configuration

Syntax: show monitor endpoint

This command displays the remote mirroring endpoint

configuration on a switch. It does not include information for any

local mirroring sessions configured on the switch. (To view a local

mirroring configuration on the switch, use show monitor [< 1-4 | name

< name-str >]; pages B-56 and B-59.)

Type: Ty pe: Indicates whether the session is a port (local) or IPv4

(remote) mirroring session.

UDP Source Addr: The IP address configured as the source VLAN

or subnet on which the traffic source exists. (For a given

mirroring session, this value should be the same on the source

and destination switches.)

UDP port: The unique UDP port number identifying a given

mirroring session. (For a given mirroring session, this value

should be the same on the source and destination switches.)

UDP Dest Addr: The IP address configured as the destination

VLAN or subnet on which the exit port exists. (For a given

mirroring session, this value should be the same on the source

and destination switches.)

Dest Port: For a given mirroring session, identifies the exit port

on the destination switch.

For example, the following output indicates that a switch is configured as the

endpoint (destination) for two remote mirroring sessions from the same

source.

ProCurve(config)# show monitor endpoint

Remote Mirroring - Remote Endpoints

Type UDP Source Addr UDP port UDP Dest Addr Dest Port

---- --------------- -------- --------------- ---------

IPv4 10.10.10.1

8001 10.10.30.2 4

8003 10.10.30.2 5

These two sessions are from the same source, and

are identified by different UPDP port numbers.

Figure B-21. Example of Displaying Only the Mirroring Endpoint Configuration
