HP ProCurve Management And Configuration Guide

Monitoring and Analyzing Switch Operation
Traffic Mirroring
Syntax: show monitor
—Continued from Previous Page—
UDP Dest Addr: The IP address configured as the destination
VLAN or subnet on which the exit port exists. (For a given
mirroring session, this value should be the same on the source
and destination switches.)
Dest Port: For a given mirroring session, identifies the exit port
on the destination switch.
For example, the following summary shows three mirroring sources (one local
and two remote) and one remote mirroring destination configured on the
switch.
Local and Remote Mirroring
ProCurve# show monitor
Sources:
• Session 1 is performing local
mirroring from an ACL source.
Network Monitoring
• Session 2 is performing remote
mirroring using non-ACL sources.
• Session 3 is not configured.
Sessions Status Type Sources ACL
• Session 4 is configured for remote
mirroring from a non-ACL source,
-------- ----------- ----- ------- ---
but is currently not mirroring any
1 active port 1 yes
traffic.
2 active IPv4 2 no
Remote Mirroring Destination:
3 not defined
The switch is configured as a
4 inactive IPv4 0 no
remote mirroring destination
(endpoint) for a source at
10.10.30.1, and is using port B10 as
Remote Mirroring - Remote Endpoints
the exit port.
Type UDP Source Addr UDP port UDP Dest Addr Dest Port
---- --------------- -------- --------------- -------- -
IPv4 10.10.30.1 7950 10.10.20.1 B10
Figure B-20. Example of a Currently Configured Mirroring Summary on a Source Switch
B-57
