HP ProCurve Management And Configuration Guide

Troubleshooting
Diagnostic Tools
Switch “A” Configured
Document
with DNS Resolver
Router “B”
Server
docservr
10.28.192.2
10.28.192.1
(10.28.229.219)
10.28.229.1
DNS Server for pubs.outdoors.com
10.28.229.10
Host Name for IP address
Domain: pubs.outdoors.com
10.28.229.219 = “docservr”
Figure C-21. Example Network Domain
Configuring switch “A” with the domain name and the IP address of a DNS
server for the domain enables the switch to use host names assigned to IP
addresses in the domain to perform ping and traceroute actions on the devices
in the domain. To summarize:
Entity: Identity:
DNS Server IP Address
10.28.229.10
Domain Name (and Domain Suffix for Hosts in
pubs.outdoors.com
the Domain)
Host Name Assigned to 10.28.229.219 by the
docservr
DNS Server
Fully Qualified Domain Name for the IP address
docservr.pubs.outdoors.com
Used By the Document Server (10.28.229.219)
Switch IP Address
10.28.192.1
Document Server IP Address
10.28.229.219
With the above already configured, the following commands enable ping and
traceroute with the host name docserver to reach the document server at
10.28.229.219.
ProCurve(config)# ip dns server-address 10.28.229.10
ProCurve(config)# ip dns domain-name pubs.outdoors.com
Figure C-22. Configuring Switch “A” in FigureC-21 To Support DNS Resolution
C-54
