HP R1500 - UPS XR User Manual

Specifications 103
UPS output specifications
3 Phase UPS NA 3 Phase UPS INTL
Nominal output voltage
120/208 Vac three-phase 230/400 Vac three-phase
Output voltage variation
(standard)
108-132 Vac phase to neutral 187-255 Vac phase to neutral
187-229 Vac phase to phase 324-441 Vac phase to phase
Output voltage variation
(reduced)
108-132 Vac phase to neutral 207-253 Vac phase to neutral
187-229 Vac phase to phase 358-438 Vac phase to phase
Output receptacles on
standalone UPSs—12kVA
models
Output module (2x L15-30R) Output module (2x IEC 309-16 A, 5
wire)
Output receptacles on
standalone UPSs—8kVA
1x L15-30R 1x IEC 309-16 A, 5 wire
Short circuit capability
(Battery Mode)
84 A, <300 ms 44 A, <300 ms
Short circuit capability
(Normal Mode)
Limited by 50 A input breaker (30 A
source on 8kVA models)
Limited by 30 A input breaker (16 A
source on 8kVA models)
Nominal output frequency
50-60 Hz auto-detection (Normal
Mode)
50-60 Hz auto-detection (Normal
Mode)
50 or 60 Hz (Battery Mode) 50 or 60 Hz (Battery Mode)
Output frequency variation
Synchronized (Normal Mode) Synchronized (Normal Mode)
±0.1 when not synchronized with
source (Battery Mode)
±0.1 when not synchronized with
source (Battery Mode)
Output overload
100-110%: load transfers to
Auto-Bypass Mode after 10 minutes
100-110%: load transfers to
Auto-Bypass Mode after 10 minutes
110-125%: load transfers to
Auto-Bypass Mode after 1 minute
110-125%: load transfers to
Auto-Bypass Mode after 1 minute
125-150%: load transfers to
Auto-Bypass Mode after 5 seconds
125-150%: load transfers to
Auto-Bypass Mode after 5 seconds
>150%: load transfers to Auto-Bypass
Mode after 300 ms
>150%: load transfers to Auto-Bypass
Mode after 300 ms
Voltage waveform
Normal Mode and Battery Mode:
Sine wave; <2% THD with linear load;
<5% with nonlinear load
Normal Mode and Battery Mode:
Sine wave; <2% THD with linear load;
<5% with nonlinear load
Full output
Three-phase Three-phase
Environmental specifications
Feature Specification
Operating
temperature
0°C to 40°C (32°F to 104°F)
Optimal battery performance: 5°C to 25°C (41°F to
77°F)
Storage temperature
0°C to 25°C (32°F to 77°F)
Transit temperature
-25°C to 55°C (-13°F to 131°F)

HP R1500 - UPS XR Specifications

General

Topology	Line Interactive
Input Connection	IEC 320 C14
Battery Type	Sealed Lead Acid (SLA)
Form Factor	Rackmount
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Input Frequency	50/60 Hz
Typical Backup Time at Full Load	5 minutes
Transfer Time	4-8 ms
Hold-up Time	10 ms
Input Voltage Range	160 - 286 VAC
Interface Port	USB
Battery Recharge Time	3 hours
Communication Ports	USB
Waveform	Sine wave
