UPS operations 72
CAUTION: If the polarity is reversed while connecting the REPO port, the UPS powers up
normally.
2. Power up the UPS.
o Standalone UPS configurationSee "Powering up the standalone UPS (on page 25)."
o Parallel UPS configurationSee "Powering up the parallel system (on page 39)."
3. Verify proper connection of the REPO port:
a. Disconnect the REPO port.
b. Reconnect the REPO port.
If the polarity is correct, the REPO connectors can be disconnected, and then reconnected, without
initiating a REPO.
c. Verify that the UPS remains in Normal mode (on page 65).
d. If a REPO is initiated, the polarity is reversed. Check and correct the connections.
Powering down the standalone UPS
1. Switch the output circuit breaker to the Off position.
2. Press any button on the front panel display to activate the menu options.
3. Select TURN UPS ON/OFF, TURN UPS OFF, and press the right arrow button.
4. Confirm the selection. Press and hold the right arrow button for three seconds, until the UPS stops
beeping.
The output relays open, the UPS transfers to Standby mode (on page 64), and the Power On LED turns
off.
5. Switch the UPS battery circuit breaker to the Off position.
6. If optional ERMs are installed, switch all ERM battery circuit breakers to the Off position.
7. Switch the UPS input circuit breaker to the Off position.
8. Press ESC until the HP logo appears.
9. Disconnect the UPS from utility power.
Powering down an individual paralleled UPS
1. Switch the output circuit breaker to the Off position.
2. Press any button on the front panel display to activate the menu options.
3. Select the TURN UPS ON/OFF, TURN UPS OFF, and press the right arrow button.
4. Confirm the selection. Press and hold the right arrow button for three seconds, until the UPS stops
beeping.
The output relays open, the UPS transfers to Standby mode, and the Power On LED turns off.
5. Switch the UPS battery circuit breaker to the Off position.
6. If optional ERMs are installed, switch all ERM battery circuit breakers to the Off position.
7. Switch the UPS input circuit breaker to the Off position.
8. Press ESC until the HP logo appears.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP R1500 - UPS XR and is the answer not in the manual?

HP R1500 - UPS XR Specifications

General IconGeneral
TopologyLine Interactive
Input ConnectionIEC 320 C14
Battery TypeSealed Lead Acid (SLA)
Form FactorRackmount
Nominal Output Voltage230V
Nominal Input Voltage230V
Input Frequency50/60 Hz
Typical Backup Time at Full Load5 minutes
Transfer Time4-8 ms
Hold-up Time10 ms
Input Voltage Range160 - 286 VAC
Interface PortUSB
Battery Recharge Time3 hours
Communication PortsUSB
WaveformSine wave
