Troubleshooting 94
Troubleshooting
LED and audible alarm troubleshooting
This UPS is designed for durable, automatic operation and also alerts you whenever potential operating
problems might occur. Usually the alarms shown on the control panel do not mean that the output power is
affected. Instead, they are preventive alarms intended to alert you of a possible condition.
The following table describes typical alarms and conditions. If an alarm appears with a service code, contact
HP technical support ("HP contact information" on page 107).
To check the Event Log for a list of active alarms:
1. Press any button on the front panel display to activate the menu options.
2. Press the down arrow button until EVENT LOG displays.
3. Press the right arrow button to display the list of alarms and conditions.
Alarm
LED
On Battery
LED
Power On
LED
Auto-Bypass
LED
Audible alarm Condition
On
UPS is in Normal
mode (on page
65).
Flashing
A new message is
active.
On
On1 beep
every 5 seconds
On Battery ("UPS is
on battery" on
page 100)
On
OnContinuous
for 10 seconds
Battery Low
("Battery low
condition" on page
96)
On
On1 beep
every 3 seconds
Battery Breaker (on
page 95)
On On1 beep
every 3 seconds
On Bypass ("UPS is
on bypass" on
page 100)
Flashing On1 beep
every 1 seconds
Bypass
Unavailable
("Bypass is
unavailable" on
page 96)
On
On1 beep
every 3 seconds
Battery Connection
("Battery
connection
condition" on page
96)
