UPS operations 68
NOTE: Menu functions related to parallel systems appear only on paralleled UPSs.
Main menu Submenu Display information or menu function
UPS Status
System Normal | High Efficiency Power: % /
Battery Resting | Battery Floating UPS in Parallel
mode / Parallel Unit Number x / Units on Bus
Bar / Units on Load
Event Log
Displays up to 100 events and alarms
Measurements
Parallel system kW (by unit) / kW (Parallel total)
Output Voltage L-N and L-L / Current / Frequency /
Power kW / Power kVA / Power pf
Battery Voltage / Current / Runtime
Input Voltage L-N and L-L / Current / Frequency
Load Receptacle Voltage / Current / Power kW / Power kVA /
Frequency
Control
Go to Bypass mode Transfers the UPS system to internal Auto-Bypass
mode
When this command is active, the option
changes to Go to Normal mode.
Start Battery Test Schedules a battery test. The battery test might
not start immediately.
Display Test Four different selectable tests for the front panel
functions:
The LEDs cycle through
The alarm sounds
The backlight turns off and on
The pixels scroll through to test the LCD
Settings
User Settings For more information, see "Changing user
settings (on page 68)."
Service Settings Not available
Identification
UPS Type / Part Number / Serial Number /
Firmware / Display / System / Parallel Card
Turn UPS On/Off
On and Off Option UPS On / UPS Off / System On / System Off
Changing user settings
Description Available settings Default setting
Set Date and Time
Set Year, Month, Day
Date: mm/dd/yyy 01/01/2003
Set Hours, Minutes 00:00
Time is a 24-hour clock
Display Contrast
Adjust contrast with up/down arrow
buttons
Moderate
Change Language
Set Language English
