Opera ting
Instructions
TEST
MODE
The Test Mode allows
the
System
Operator
to select portions
of
the
Power-on
Self Test
or
an
additional
CPU test wit., failures displayed on
the
System Console. The Test Mode also allows
for
looping
up
to
9999
times, the
default
is
I.
The
Maintenance
mode TEST command accesses
the
Self Test mode. Table
2-4
lists
the
commands
available in Test Mode.
REMOTE OPERA TOR INTERFACE
The remote System
Operator
interface
is enabled
if
all
of
the
following conditions
are
met:
• The Console
is
connected
to
Port 7
of
TIC
in
Slot I via modem or hardwi
,'?
configuration.
• The keyswitch is
in
Remote (or Local
after
having been
in
Remote,
but
not
s\'(;tched
through
Normal) mode
and
the
REMOTE LED
is
on.
• The System Console,
the
modem,
and
the
remote
como
Ie
are
all
operating
at
the
same baud
rate.
• The
hardwire
configuration
requires a
standard
25
pin
straight
through
mod~m
cable
with
pins 4
and
22 to be tied together.
Table
2-4.
Test Mode Commands
r---'
------------~--------------------------------------.--------------_.
Command
Description
~'------------~------------------------------------------------------1
ALL
CHANNEL
CPU
EXIT
HELP
IOMAP
MEMORY
PON
Run
all self tests
1-9999
times.
Loop Test
of
channel
1-9999
times.
Loop
CPU test
1-9999
times.
Return
to
Maintenance
Mode.
Lists Test Mode Commands
and
display ROM version numbers.
Loop
IOMAP
1-9999
times.
Loop memory test
1-9999
times.
Run
(or loop)
Power-on
Self Test.
NOV 84
2-5/6
To Next Page
