Computer components
This section describes the computer components, including front and rear panel components.
For complete and current information on supported accessories and components for the computer,
see
http://partsurfer.hp.com.
Chassis components
The following image shows the components of a typical computer layout. Drive configurations can vary.
Figure 1-2 Computer components
Table 1-1 Computer component descriptions
Item Description Item Description
1 Access panel 8 System fan
2 Processor (CPU) 9 Chassis
3 Heatsink 10 Front bezel
4 PCIe card 11 Speaker
5 System board 12 Optical drive
6 Hard disk drive 13 Optional media reader or second
hard disk drive
7 Airflow guide
4 Chapter 1 Product overview ENWW
