Front bezel security
You can lock the front bezel in place by installing a security screw provided by HP. To install the security
screw:
1. Prepare the computer for servicing by following the
Predisassembly procedures on page 68.
CAUTION: Failure to follow the predisassembly procedures can result in equipment damage or
data loss.
2. Remove the access panel (see Removing the access panel on page 71).
3. Remove the front bezel (see
Removing the access panel on page 71).
4. Remove one of the five silver 6-32 standard screws located on the front of the chassis behind the
bezel.
Figure 5-5 Retrieving the Front Bezel Security Screw
5. Replace the front bezel.
ENWW Removing and installing components 73
