6. Install the security screw next to the middle front bezel release tab to secure the front bezel in
place.
Figure 5-6 Installing the Front Bezel Security Screw
7. Replace the access panel.
8. Reconnect all connections and equipment listed in the
Predisassembly procedures on page 68.
Access panel sensor (optional)
The access panel sensor is a remote solenoid that detects when the access panel is opened. This
section describes how to remove and install the sensor.
Removing the access panel sensor
To remove the access panel sensor:
1. Prepare the computer for servicing by following the
Predisassembly procedures on page 68.
CAUTION: Failure to follow the predisassembly procedures can result in equipment damage or
data loss.
2. Remove the access panel (see Removing the access panel on page 71).
74 Chapter 5 Replacing components ENWW
