Installing a DIMM
To install the DIMM:
1. Prepare the computer for servicing by following the
Predisassembly procedures on page 68.
CAUTION: Failure to follow the predisassembly procedures can result in equipment damage or
data loss.
2. Remove the access panel (see Removing the access panel on page 71).
3. Rotate the drive cage to its upright position.
Figure 5-47 Rotating the drive cage up
4. Push gently outward on the DIMM socket levers.
108 Chapter 5 Replacing components ENWW
