HP zl User Manual

119
12
Viewing the IB Network Through the GUI
This chapter provides the following information:
• “About the Device Manager (DM)” on page 119
• “Display the Device Manager” on page 119
• “About the Topology View” on page 121
• “Display the InfiniBand Topology” on page 122
• “View the Internal Chassis Topology” on page 127
• “View Subnet Manager Details” on page 129
About the Device Manager (DM)
Use the Device Manager to view the InfiniBand I/O units, I/O Controller information, and I/O
Controller services.
The Device Manager is available through the Element Manager GUI, the Chassis Manager GUI, as well
as the CLI.
Display the Device Manager
View I/O Unit Information
1. Launch Element Manager, if you have not already done so.
2. Select InfiniBand --> DM
