14
Verify Switch to Host Communication
To verify the InfiniBand device can reach a host on the network, enter either the user-execute or
privileged-execute mode on the InfiniBand device, then enter the
ping
command. This is an In-band
procedure only.
Install the GUI (Element Manager)
HP 24-Port 4x Fabric Copper Switches can be managed visually through the Element Manager, which
provides a wide range of configuration, monitoring, and troubleshooting options.
Refer to “Installing the Element Manager Program” on page 27 for information regarding the Element
Manager installation.
Access a Management System
Default User Name and Passwords
For initial configuration, log in as the unrestricted user.
• The default unrestricted username for the CLI is
super
and the default password is
super
.
• The default community-string assigned to this user for the Element Manager is
secret
.
Use the following methods to manage the Topspin system.
CLI Management
Refer to “About the CLI” on page 19 for more information about managing through the CLI.
Run the Command Line Interface (CLI) from one of the following methods:
• “Direct Serial-Console Connection” on page 14
• “Remote Telnet Login” on page 14
• “Remote SSH Login” on page 15
Direct Serial-Console Connection
Refer to the HP Serial Managment Cable Guide for information regarding setting up the physical
serial-console connection.
Remote Telnet Login
You can Telnet to the Management-Ethernet port on the box from a host on the same network as the
Management-Ethernet port, or from any host with a route to the Management-Ethernet network.
Topspin-360# ping 10.10.253.47
Sending 5 ICMP Echos to 10.10.253.47, 56 data bytes
!!!!!
Success rate is 100 percent (5/5)
round-trip min/avg/max = 0.000000/0.000000/0.000000 ms
Topspin-360#
