10
Install HCAs and Drivers in Hosts
Refer to the HP Dual-port 4x Fabric Adapter Quick Setup Installation card and the HP Dual-port 4x
Fabric Adapter User Guide.
Install and Power on the InfiniBand Chassis
Refer to the HP 24-Port 4x Fabric Copper Switch Hardware Quick Setup Installation card and the HP
24-Port 4x Fabric Copper Switch Hardware User Guide for installation and power instructions.
Configure Basic Connectivity
The InfiniBand switch is not pre-configured with an IP address. You must configure the IP address of a
management port to administer and monitor the InfiniBand switch with the CLI and Element Manager.
A Management port is provided for a connected Ethernet host running TCP/IP or connected InfiniBand
hosts running IPoIB. Configure the Management port you wish to use.
“Configuring an Ethernet Management IP Address” on page 10
“Configuring an InfiniBand Management IP Address” on page 12
Configuring an Ethernet Management IP
Address
To configure an out-of-band Ethernet Management IP address:
1. Make sure that the InfiniBand switch is attached to a PC or terminal via the serial port. Refer to the
HP 24-Port 4x Fabric Copper Switch Hardware Quick Setup Installation card and the HP 24-Port
4x Fabric Copper Switch Hardware User Guide.
2. Open a terminal emulation program, such as HyperTerminal for Windows
®, and set the session
parameters as follows:
Baud: 9600 b/s
Data Bits: 8
•Parity: None
Stop Bits: 1
Flow control: None
3. At the Login: prompt, enter the username and password. The default is super and super.
Example
4. At the CLI prompt, enter enable. This enters the privileged-execute mode.
5. Enter configure to enter the global-configuration mode.
Login: super
Password: super
Topspin-360>
Topspin-360> enable
Topspin-360# configure
Topspin-360(config)#
