hpmont HD3N Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 113 -
Ref. Code
Function Setting Range Default Unit Attribute Setting
d00.52
MODBUS communication
status
0: Normal
1: Communication timeout
2: Wrong data Frame head
4: Wrong data Frame content
*
d00.53 Actual length (m) 0 - 65535m *
d00.54 Accumulative length (km) 0 - 65535km *
d00.55 Total power up time (h) 0 - 65535h *
d00.56 Total running time (h) 0 - 65535h *
d00.57
Total energy consumption
high bit of motor (k kW.h)
0 - 65535k kW.h *
d00.58
Total energy consumption
low bit of motor (k kW.h)
0.0 - 999.9kW.h *
d00.59
Present energy
consumption high bit (k
kW.h)
0 - 65535k kW.h *
d00.60
Present energy
consumption low bit (k
kW.h)
0.0 - 999.9kW.h *
d00.61 Present fault
0 - 100
100: Under-voltage
*
F00: Basic Parameters (on pages 49 - 53)
F00.00 Motor control mode
0: Speed control
1: Torque control
0 1
×
F00.01 Motor control mode
0: V/f control without PG
2: Vector control without PG
0 1
×
F00.06
Max. output frequency of
HD3N
50.00 - 400.00Hz 50.00Hz 0.01Hz
×
F00.07
Upper limit of running
frequency setting channel
0: Digital setting (F00.08)
1: Analogue input setting
2: Terminal pulse setting
3 - 4: AI1 - AI2
7: Potentionmeter
0 1
×
F00.08
Upper limit of running
frequency
0.00 - F00.06 50.00Hz 0.01Hz
×
F00.09
Lower limit of running
frequency
0.00 - F00.08 0.00Hz 0.01Hz
×
F00.10
Frequency setting
channels
0: Keypad
1: Terminal
2: SCI communication
3: Analogue
4:DI6 pulse
6 - 7: AI1 - AI2
10: Potentionmeter (Valid when LED
keypad adopted only)
0 1
○
A
