Page #135 background imageLoading...
Page #135 background image
Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
- 116 - HD3N Series User Manual V1.1
Ref. Code
Function
Setting Range Default
Unit
Attribute Setting
F01.02
Function code parameter
initialization (download)
0: No operation
1: Restore to factory settings
2/3: Download the keypad EEPROM
parameter 1/2 to the current
function code settings
4: Clear fault information
5/6: Copy the keypad EEPROM
parameter 1/2 to the current
function code settings (including the
motor parameters)
2/3/5/6 is valid when LED keypad
adopted
0 1
×
F01.03
Copy parameter to keypad
(upload)
0: No operation
1/2: Copy the current function code
settings to keypad EEPROM
parameter 1/2
1/2 is valid when LED keypad adopted
0 1
F02: Parameters for Start and Stop ( on pages 54 - 57)
F02.00 Start mode
0: Start from starting DWELL
frequency
1: Brake and then start from starting
DWELL frequency
2: Rotate speed tracking re-start
0 1
×
F02.01 Start delay time 0.00 - 10.00s 0.00s 0.01s
×
F02.02
Starting DWELL frequency
setting
0.00F00.08 0.00Hz 0.01Hz
×
F02.03
Starting DWELL retention
time
0.00 - 10.00s 0.00s 0.01s
×
F02.04 Current at DC brake
0 - 100% (rated current of HD3N) 50% 1%
×
F02.05 DC brake starting time
0.00 - 60.00s 0.50s 0.01s
×
F02.06
Compensation for full
speed tracking
0.000 - 2.000Hz 0.000Hz 0.001Hz
F02.13
Stop modes at speed
control
0: Decelerate to stop
1: Coast to stop
2: Decelerate to stop+DC brake
0 1
×
F02.14
Stop DWELL frequency
setting
0.00 - upper limit frequency 0.00Hz 0.01Hz
×
F02.15
Stop DWELL frequency
retention time
0.00 - 10.00s 0.00s 0.01s
×
F02.16
Starting frequency of stop
DC brake
0.00 - 50.00Hz 0.50Hz 0.01Hz
×
F02.17
Waiting time of stop DC
brake
0.00 - 10.00s 0.00s 0.01s
×
F02.18 Stop DC brake time
0.00 - 60.00s 0.50s 0.01s
×
F02.19 Jog control mode
Units:
0: Can not jog the start and stop
function
10 1
×
