Page #136 background imageLoading...
Page #136 background image
Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD3N Series User Manual V1.1 - 117 -
Ref. Code
Function
Setting Range Default
Unit
Attribute Setting
1: Can jog the start and stop
function
Tens:
0: Terminal jog is not preferred
1: Terminal jog is preferred
F02.20 Pre-excitation time 0.00 - 0.50s 0.50s 0.01s
×
F02.21
End selection of DWELL
frequency in stop
0: Time (F02.15)
1: Terminals (88 function)
0 1
×
F03: Acc. / Dec. Parameter (on pages 57 - 58)
F03.00
Acc. / Dec. modes
selection
Unit: Acc. / Dec. modes selection
0: Linear Acc. / Dec.
1: S curve Acc. / Dec.
Ten: Reference frequency for Acc. /
Dec. time
0: Max frequency (F00.06)
1: Setting frequency
00 1
F03.01 Acc time 1 0.0 - 6000.0s
7.5 - 15kW
inverter:
10.0s
18.5kW
inverter:
30.0s
0.1s
F03.02 Dec time 1 0.0 - 6000.0s 0.1s
F03.03 Acc time 2 0.0 - 6000.0s 0.1s
F03.04 Dec time 2 0.0 - 6000.0s 0.1s
F03.05 Acc time 3 0.0 - 6000.0s 0.1s
F03.06 Dec time 3 0.0 - 6000.0s 0.1s
F03.07 Acc time 4 0.0 - 6000.0s 0.1s
F03.08 Dec time 4 0.0 - 6000.0s 0.1s
F03.09
Switching frequency of
acc time 1 and 2
0.00 - upper limit frequency 0.00Hz 0.01Hz
×
F03.10
Switching frequency of
dec time 2 and 1
0.00 - upper limit frequency 0.00Hz 0.01Hz
×
F03.11
Characteristic time of S
curve at beginning of acc
0.00 - 2.50s 0.20s 0.01s
F03.12
Characteristic time of S
curve at end of acc
0.00 - 2.50s 0.20s 0.01s
F03.13
haracteristic time of S
curve at beginning of dec
0.00 - 2.50s 0.20s 0.01s
F03.14
Characteristic time of S
curve at end of dec
0.00 - 2.50s 0.20s 0.01s
F03.15 Jog acc time 0.1 - 6000.0s 6.0s 0.1s
F03.16 Jog dec time 0.1 - 6000.0s 6.0s 0.1s
F03.17 Dec time for EMR stop 0.1 - 6000.0s 10.0s 0.1s
F04: Process PID Control (on pages 58 - 61)
F04.00
Process PID control
selection
0: PID control is disabled
1: PID control is enabled
0 1
×
