Table 4-5 DIP switch setting on a T/H sensor
Address DIP Switch Sequence No.
1 2 3 4 5 6
1 ON OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF
The default address of T/H sensors purchased from Huawei is 1.
Step 3 Insert the pre-routed cable into the port on the T/H sensor on the front and rear
doors.
----End
4.2.6.4 Installing T/H Sensors
Procedure
Step 1 Install T/H sensors.
1. Open the front and rear doors of the cabinet.
2. Unpack the two T/H sensors and attach one sensor to the mounting bars at
the 39th U position on the front door and the other to the 37th U position on
the rear door of the cabinet.
The installation positions of the T/H sensors can be adjusted as required.
Step 2 Set the DIP switch address of the T/H sensor on the front door to 2 and that of
the T/H sensor on the rear door to 1.
Table 4-6 DIP switch setting on a T/H sensor
Address
DIP Switch Sequence No.
1 2 3 4 5 6
1 ON OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF
The default address of T/H sensors purchased from Huawei is 1.
FusionModule500 Smart Mini Data Center
User Manual 4 Installation Guide
Issue 01 (2020-11-30) Copyright © Huawei Technologies Co., Ltd. 81
