Step 3 Connect one end of the RJ45 network cable to the AI/DI port on the ECC500 collector.
----End
4.3.4.5 Connecting a Monitoring Cable to a WS332M2-5 Ambient
Temperature and Humidity Sensor
Prerequisites
A monitoring cable is prepared.
Procedure
Step 1 Connect one end of the network cable to the wiring port on the T/H sensor.
Step 2 Connect the other end of the network cable to the COM4/12V or COM5/12V port on the
ECC500 collector.
A maximum of eight T/H sensors can connect to each port.
----End
4.3.4.6 Connecting Cables to the Region-type Water Sensor
Prerequisites
A monitoring cable is prepared.
Procedure
Step 1 Connect one end of the network cable to the Ethernet port on the water detector.
Step 2 Connect the other end of the network cable to the AI/DI port on the ECC500 collector.
----End
4.3.4.7 Connecting Cables to the Location-type Water Sensor
Prerequisites
A network cable used for monitoring is prepared.
Procedure
Step 1 Connect one end of the network cable to the RJ45 port on the tie line.
Step 2 collector.Connect the other end of the network cable to the COM4/12V or COM5/12V port on
the ECC500 collector.
----End
