4 Connecting Monitoring Cables to Devices
Issue 03 (2019-03-10)
Copyright © Huawei Technologies Co., Ltd.
79
Procedure
Step 1 Connect one end of the network cable to the fast Ethernet (FE) port on TP483000D.
Step 2 Connect the other end of the network cable to the Ethernet port on the switch.
----End
4.2.8 Connecting a Monitoring Cable to a CIM01C2
Prerequisites
A network cable used for monitoring is prepared.
Procedure
Step 1 Connect one end of the network cable to the PoE port on the CIM.
Step 2 Connect the other end of the network cable to the Ethernet port on the switch.
----End
4.3 Scenarios for Connecting the ECC500 Collector
4.3.1 Preparing a Monitoring Cable
Prerequisites

A twisted pair, cord end terminal, and RJ45 connector are prepared.

The following tools are prepared:
− Wire stripper
− Crimping tool
− RJ11 crimping tool
− Electrician's knife
− Polyvinyl chloride (PVC) insulation tape
Preparing a Cord End Terminal
Figure 4-26shows how to prepare a cord end terminal.
