Huawei iManager NetEco 6000 User Manual

iManager NetEco 6000
Device Installation and Commissioning Guide
6 Adding Devices
Issue 03 (2019-03-10)
Copyright © Huawei Technologies Co., Ltd.
231
Table 6-38 Parameter description
Parameter
Description
Communication address
1–255
Indicates the actual address for the
NetCol5000. The devices with the same
address cannot connect to the same port.
When creating a NetCol5000 on the
NetEco, set Device address to the same
value.
Baud Rate
9600, 19200
Indicates the baud rate. The default baud
rate is 9600. Set BaudRate for the collector
port to the same value.
The NetCol5000 DataBit, StopBit, and Parity cannot be set on the WebUI. Their default
values are 8, 1, and None respectively.
Step 5 Set RS485 port parameters for the collector based on the value of BaudRate, DataBit,
StopBit, and Parity of the device. For ECC collector settings, see 6.4.1.4 Setting RS485
Parameters for the ECC500 V6 Collector.
----End
6.4.4.2 Creating a Smart Cooling Product on the NetEco
Prerequisites

You have logged in to the NetEco client.

You have the operation rights for Data Center Planning.

You have created a management domain for the device to be added on the Data Center
Planning page.
Procedure
Step 1 Choose Configuration > Configuration Management > Data Center Planning from the
main menu. The Data Center Planning window is displayed.
Step 2 Select the management domain to add a device.
Step 3 In the lower-left corner of the page, click the Device tab.
Step 4 Click the drop-down list box in Type and select Air Conditioner.
Step 5 Select the device to be added and drag its icon to the management domain.
To delete a device, click the device and choose Delete under .
Step 6 Specify parameters shown in Figure 6-80 in the right pane based on the following table. The
NetCol5000 smart cooling product complying with the MODBUS-RTU protocol is used as an
example.
