iManager NetEco 6000
Device Installation and Commissioning Guide
4 Connecting Monitoring Cables to Devices
Copyright © Huawei Technologies Co., Ltd.
97
Terminal Identity
Definition
R-D0
Card reader data 0
R-Gnd
Card reader public ground
R-12V
Reader power + 12 V
Table 4-16 Lock and door magnetic terminal definition
Terminal Identity
Definition
LK+
Lock output power +
LK-
Lock output power -/Passive output -
NP
Passive output +
LKS
Lock signal input +
ST
Door magnetic signal input +
Gnd
Common ground
Table 4-17 Alarm input terminal definition
Terminal Identity
Definition
AL(1-2)
Two-door controller, no power supply output signal
AL(1-4)
Four-door controller, no power supply output signal
Gnd
Common ground
Table 4-18 Power terminal definition
Terminal Identity
Definition
LK-P
+12V
Lock the power input + 12 V
GND
Lock the power input -
BAT
+
Battery +
-
Battery -
DC
+12V
The controller + 12 V DC power DC input
GND
Controller DC power input-
AC
11V
The controller 11 V AC power input
