iManager NetEco 6000
Device Installation and Commissioning Guide
Copyright © Huawei Technologies Co., Ltd.
Figure 7-6 Installing a hydrogen detection system
Step 5 Install components and connect cables as shown in Figure 7-7 and Figure 7-8.
Pay attention to the negative and positive polarities of the power supply. If the polarities are
connected incorrectly, the device may be burned.
