iManager NetEco 6000
Device Installation and Commissioning Guide
Copyright © Huawei Technologies Co., Ltd.
Procedure
Step 1 Bind temperature sensors to the cabinet frames of corresponding cabinets using cable ties.
When installing temperature sensors on the front door, route the sensors through the
sponge strips at rack rails and then secure the sensors.
When installing temperature sensors, bind the cables behind the sensors to the cabinet,
keeping them 20 mm away from the sensor probes.
The temperature sensor must not be in touch with metal parts or cabinets.
Ensure that the temperature sensors are installed on the side without a PDU2000 on the
cabinet rear.
Keep the temperature sensors facing the inside of the cabinets to ensure accurate
measurement of cabinet interior temperatures.
Figure 3-10 The appearance of the NTC Temperature sensor
