Huawei iSitePower-M User Manual

Label Item Description
Burn warning Do not touch the
product because the
enclosure is hot when
it is running.
Delayed discharge High voltage still exists
after the product is
powered o. It takes 5
minutes for the
product to discharge
to the safe voltage.
Operation ● High voltage exists
after the product is
powered on. Only
qualied and
trained electrical
technicians are
allowed to install
and operate the
product.
● Ground the product
before powering it
on.
Refer to
documentation
Reminds operators to
refer to the
documentation of the
battery module.
Operation warning Do not remove the
connector when the
product is running.
Grounding label Indicates the position
for connecting the
ground cable.
Serial number label Indicates the product
SN.
MAC address label Indicates the MAC
address.
iSitePower-M (MAP05A1, MAB05B1)
User Manual 3 Product Description
Issue 02 (2021-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 19

Huawei iSitePower-M Specifications

General

Storage Temperature	-40°C to +70°C
Product Name	Huawei iSitePower-M
Type	Power System
Efficiency	≥96%
Output Voltage	-48 V DC
Operating Temperature	-40°C to +55°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 4000 m
Cooling Method	Forced Air Cooling
Protection Features	Overvoltage, undervoltage, overcurrent, short circuit, overtemperature
Certifications	CE, UL, TUV
Input Voltage Range	85 V - 300 V AC
