Huawei iSitePower-M User Manual

Label Item Description
WiFi login QR code Scan the QR code to
connect to the WiFi
network of the product
and log in to the
product to set
parameters locally.
NO TE
The labels are for reference only.
Nameplate
Power module nameplate
Figure 3-5 Nameplate (power module)
Battery module nameplate
iSitePower-M (MAP05A1, MAB05B1)
User Manual 3 Product Description
Issue 02 (2021-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 20

Huawei iSitePower-M Specifications

General

Storage Temperature	-40°C to +70°C
Product Name	Huawei iSitePower-M
Type	Power System
Efficiency	≥96%
Output Voltage	-48 V DC
Operating Temperature	-40°C to +55°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 4000 m
Cooling Method	Forced Air Cooling
Protection Features	Overvoltage, undervoltage, overcurrent, short circuit, overtemperature
Certifications	CE, UL, TUV
Input Voltage Range	85 V - 300 V AC
