Cable Type
Table 7-1 Cables prepared by the customer (standard scenario)
No. Cable Type Recommended Specications Source
1 PV input
power cable
Common
outdoor PV
cable in the
industry
● Conductor cross-sectional area: 4–6 mm
2
● Cable outer diameter: 5.5–9 mm
Prepared
by the
customer
2 AC input and
output
power cables
Outdoor
three-core
copper cable
(L/N/PE)
● Conductor cross-sectional area: 4–6 mm
2
● Cable outer diameter: 13.7–16.9 mm
Prepared
by the
customer
3 Ground cable Outdoor
single-core
copper cable
Main ground cable: 4–6 mm
2
(same as the
cross-sectional area of the AC input power
cable)
Ground cable between battery modules
(capacity expansion scenario): 6 mm
2
Prepared
by the
customer
4 Dry contact
signal cable
Outdoor
shielded
twisted pair
cable (8
cores)
● Conductor cross-sectional area: 0.2–1 mm
2
● Cable outer diameter: 6.3–7.5 mm
Prepared
by the
customer
Table 7-2 Cables prepared by the customer for the AC parallel box (parallel system scenario)
No.
Cable Type Recommended Specications Source
1 AC input power
cable from the
mains input to
the parallel box
Outdoor
three-core
copper
cable
(L/N/PE)
● Conductor cross-sectional area: 25 mm
2
● Cable outer diameter: 16–26 mm
Prepared
by the
customer
2 Cable from the
parallel box to
the iSitePower-
M AC input
port
Outdoor
three-core
copper
cable
(L/N/PE)
● Conductor cross-sectional area: 4–6 mm
2
● Cable outer diameter: 13.7–16.9 mm
Prepared
by the
customer
3 Cable from the
iSitePower-M
AC output port
to the parallel
box
Outdoor
three-core
copper
cable
(L/N/PE)
● Conductor cross-sectional area: 4–6 mm
2
● Cable outer diameter: 13.7–16.9 mm
Prepared
by the
customer
iSitePower-M (MAP05A1, MAB05B1)
User Manual 7 Electrical Connection
Issue 02 (2021-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 58
