NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm)
Copyright © Huawei Technologies Co., Ltd.
4.4.1.5 Querying Component Status
Context
You can query component status in the following two ways.
Enter the Status screen. The control or running status of major components such as the
compressor, indoor fan, outdoor fan, electric heater, humidifier, and chilled water valve
is displayed.
Enter the Device Details screen and then enter the menu of a specific component. All
parameters for the component are displayed.
Procedure
When viewing the component status through Status, choose Common Functions >
Status or Running > Status on the home screen. The general component status screen is
displayed. Figure 4-32 shows the screen displayed after choosing Running > Status.
Figure 4-32 General status
The actual number of devices is displayed on the screen. If two indoor fans are used, indoor fan 1 and
indoor fan 2 are displayed. This is also the case for other devices.
When querying component status through Device Details (using the compressor as an
example), choose Running > Device Details > Compressor on the home screen to
query the status of the compressor and solenoid valve, as shown in Figure 4-33.
